RODUCT NUMBER RR-212S-20PC-R1
CPU SOCKET LGA2066 LGA2011-v3 LGA2011 LGA1200 LGA1151 LGA1150 LGA1156 LGA1155 LGA1366 AM4 AM3+ AM3 AM2+ AM2 FM2+ FM2 FM1
DIMENSIONS (L X W X H) 120 x 79.6 x 158.8 mm - 4.7 x 3.1 x 6.3 inch
HEAT SINK MATERIAL 4 Heat Pipes Aluminum Fins Direct Contact
FAN DIMENSIONS (L X W X H) 120 x 120 x 25mm
FAN QUANTITY 1 PCS
FAN SPEED 650-2000 RPM (PWM) ± 10-por-ciento
FAN AIRFLOW 57.3 CFM (Max)
FAN AIR PRESSURE 2.0 mmH2O
FAN MTTF 160000 Hours
FAN NOISE LEVEL 8 - 30 dBA
FAN POWER CONNECTOR 4-Pin (PWM)
FAN RATED VOLTAGE 12VDC
FAN RATED CURRENT 0.16A
FAN SAFETY CURRENT 0.37A
FAN POWER CONSUMPTION 1.92W
WARRANTY 2 years
