SERIES
MasterBox Series
SIZE
Mid Tower
AVAILABLE COLOR(S)
Black
MATERIALS
Steel Mesh Plastic Tempered Glass
DIMENSIONS (L X W X H)
499.3 x 208.6 x 498mm (incl. Protrusions) 488.3 x 208.6 x 498mm (excl. Protrusions)
VOLUME (EXLC. PROTRUSIONS)
51.87L
MOTHERBOARD SUPPORT
Mini ITX Micro ATX ATX E-ATX* (*up to 12” x 10.7” motherboards may impact cable management feature)
EXPANSION SLOTS
7
5.25a DRIVE BAYS
0
2.5a - 3.5a DRIVE BAYS (COMBO)
2
2.5a DRIVE BAYS
4
I-O PANEL
2x USB 3.2 Gen 1 Type-A 1x USB 3.2 Gen 2 Type-C 1x 3.5mm Headset Jack (Audio+Mic) 1x Reset-ARGB button
PRE-INSTALLED FANS - TOP
N-A
PRE-INSTALLED FANS - FRONT
N-A
PRE-INSTALLED FANS - REAR
1x 120mm 650~1800RPM SickleFlow PWM ARGB
FAN SUPPORT - TOP
3x 120mm 2x 140mm
FAN SUPPORT - FRONT
3x 120mm 2x 140mm
FAN SUPPORT - REAR
1x 120mm
RADIATOR SUPPORT - TOP
120mm 140mm 240mm 280mm 360mm (recommended maximum thickness -55mm)
RADIATOR SUPPORT - FRONT
120mm 140mm 240mm 280mm 360mm
RADIATOR SUPPORT - REAR
120mm
CLEARANCE - CPU COOLER
165mm-6.49a
CLEARANCE - PSU
180mm-7.08a 295mm-11.61a (w- HDD cage removed)
CLEARANCE - GFX
410mm-16.1a
DUST FILTERS
Top Front Bottom
POWER SUPPLY SUPPORT
ATX
