Model Mecha
Case Type Mid Tower
Color Black
Body Material SPCC
Front Panel Material ABS
Steel Thickness 0.5mm
Motherboards ATX-micro ATX-mini-ITX
Case Dimensions (Internal) 200 x 430 x 305mm (W x H x D)
Case Dimensions (Overall) 205 x 442 x 370mm (W x H x D)
3.5” Drive Bays 2 Max. (1 x 3.5” and 1 x 3.5”-2.5)
2.5” Drive Bays 3 Max. (2 x 2.5” and 1 x 2.5”-3.5”)
Expansion Slots 7
GPU Clearance Supports GPU up to 302mm (without front fan)
CPU Clearance Supports CPU up to 159mm
Air Cooling Front: 120mm x 2 or 140mm x 2 (Max.)
Top: 120mm x 1 (Max.)
Rear: 120mm x 1 (Optional)
Liquid Cooling
Front: 120-240mm Radiator (Optional)
Rear: 120mm Radiator (Optional)
I-O Ports USB3.0 x 2 | HD Audio - Mic. (Mecha-G-BK-v3: USB3.0 x 2 + USB2.0 x 1)
Internal Cable Management Depth 18.9mm
Power Supply ATX PSU (Including cables up to 160mm) (Optional)
EAN Code Mecha-G-BK-v1: 4710562756296 (Includes 120mm Black Fan x 1)
Mecha-G-BK-v3: 4710562757835 (Includes 120mm RGB Fan x 1)
