MODEL
MPY-6501-ACAAG
ATX VERSION
ATX 12V V2.31
PFC
Active PFC (>0.95 typical)
INPUT VOLTAGE
100-240V
INPUT CURRENT
12-6A
INPUT FREQUENCY
50-60Hz
DIMENSIONS (L X W X H)
140 x 150 x 86 mm
FAN SIZE
120mm
FAN BEARING
LDB
POWER GOOD SIGNAL
100 - 500 ms
HOLD UP TIME
>14ms at 100-por-ciento load
EFFICIENCY
90-por-ciento Typically
ERP 2013 LOT 6
Yes
MTBF
>100000 Hours
OPERATING TEMPERATURE
0-45°C
PROTECTIONS
OPP OVP UVP SCP OTP OCP
REGULATORY
CCC CE TUV-SUD RCM EAC cTUVus FCC BSMI CB
MB 24-PIN CONNECTORS
1
CPU 12V 4+4 PIN CONNECTORS
1
CPU 12V 8 PIN CONNECTORS
1
SATA CONNECTORS
8
PERIPHERAL 4-PIN CONNECTORS
6
FDD CABLE 4-PIN CONNECTORS
1
PCI-E 6+2 PIN CONNECTORS
4
80 PLUS
Gold
